P16 Ultra Thin Led Display Outdoor With G Energy Power Supply And Meanwell Driver
Customer Service
1) Warranty Period: One year after shipment from the factory
2) Warranty coverage: LED modules, power supplies, control systems and other accessories (this warranty does not cover accessories purchased from other manufacturers)
3) Repair Method:
Repair, express delivery, etc.
4) Repair response time:
Repair method: Upon receipt of the returned product, the repair will be completed and returned to the user within 24 hours;
Telephone or Internet: contact the user within 2 hours after receiving the information, and provide a solution within 8 hours;
On-site mode: (domestic users only) after receiving the repair information, users in Guangdong Province will give a reply within 48 hours, and users outside Guangdong Province will give a reply within 72 hours. Under special circumstances, the two sides will solve the problem by friendly negotiation.
Specifications:
| outdoor DIP 16 LED Display |
| Resolution/mm | 16mm |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 3906/sqm |
| Module resolution | 16x16 |
| Module size/mm | 256x256m |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | static full color |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Upgrade Service :
Unschedule,we will upgrade our system of products without extra formal; we'll do our best to help users with upgrading ; the following conditions are excluded by this warranty :
- Without approved documents;
- Series code on products having been torn or changed ;
- Damage caused by lighting strike or electrical problems;
- Risks caused by irresistible incidents includes all kinds of natural disasters, fire, wars, policy changes, and some other human error accidents.
- Users or third party refit or repaired by themselves without SCX permission ;
- Water intrusion or corrosion caused by improper keeping or operating ;
- Over period of free maintenance .
FAQ
Q1: How to help client choose suitable display?
A1:
(1)specific application scenario
(2)viewing distance requirement
(3)display brightness requirement
(4)specific installation environment
(5)budget and cost control
Q2: What about your technical support?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required.
Q3: What's the control system?
A3: For synchronization control: Nova, Linsn or Mooncell control system.
For asynchronous control: Onbon or Xixun control system.
Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.
Q5: What's your payment method?
A5: Our payment method is T/T 30% as deposit, balancing before delivery.
Product Tags:
|
|
Die-cast Aluminum Screen Fixed Installation/Rental Customizable P16 Outdoor Waterproof LED Screen Images
|
